| Stockcode | : | 671559 |
| Type | : | CNC Lathes |
| Subtype | : | Turning Centres |
| Manufacturer | : | DOOSAN DAEWOO |
| Model | : | LYNX 200 A |
| Year | : | 2000 |
| Price | : | P.O.A. |
| Description | : | |
|
turning diameter 460 mm
turning length 300 mm control Fanuc 21-T turning diameter over bed 460 mm turning dia. over face-slide 280 mm travel -x axis 160 mm travel -z axis 330 mm centre distance 335 mm feeds: rapid traverse X-axis 12 m/min rapid traverse Z-axis 15 m/min Main spindle turning speed range - main spindle 42 - 4.000 U/min spindle nose A2-6 spindle passage 51 mm spindle bore 65 mm spindle cone 1/20 power capacity - main spindel 7.5 kW no. of tool upper turret 10 . Shank diameter 32 (rund) mm Shank diameter 20 (vierkant) mm tube diameter max. 50 mm chucking diameter 200 mm tail stock dia. of quill 65 mm quill stroke 80 mm capture MT 4 coolant tank 87 l total power requirement 15 kW weight of the machine ca. 3,2 t dimensions of the machine ca. 1,9 x 1,5 x 1.5 m Accessories Chip conveyor Coolantsystem Additional information CNC - Lathe LYNX 200 L | ||
