| Stockcode | : | 670349 |
| Type | : | CNC Lathes |
| Subtype | : | Turning Centres |
| Manufacturer | : | ECOCA |
| Model | : | EL 4610 |
| Year | : | 2009 |
| Price | : | P.O.A. |
| Description | : | |
|
turning diameter 225mm
turning length 1.000mm control Siemens 810 D turning diameter over bed 460mm turning dia. over face-slide 258mm x-axis 210mm z-axis 580mm Slide cross 127 / 110mm turning speed range - main spindle 95 - 3.000min/-1 transmission ratio 4 power capacity - main spindel 7,5 / 9,3kW spindle nose ASA D1-6" spindle bore 78mm bar material dia. 58mm bed width 300mm taper of center MT 4 tailstock adjustment 127mm dia. of quill 68mm tool taper MultiFix B rapid traverse 5m/min power feed longitudinal 5.000N power feed coss 2.400N total power requirement ca. 15kW weight of the machine ca. 1,8t dimensions of the machine ca. 3,5 x 2,0 x 2,0m Equipment Documents Tailstock Signal-Light hydraulic system Three Jaw Chuck 9" 4-Jaw-Chuck 10" Other information CNC - Lathe ECOCA - EL 4610 | ||
| View all |
|
ECOCA (4) EL 4610 (1) CNC Lathes (382) Turning Centres (337) |
Germany
