| Stockcode | : | 670260 |
| Type | : | CNC Lathes |
| Subtype | : | Turning Centres |
| Manufacturer | : | NAKAMURA |
| Model | : | TW 10 MM |
| Year | : | 2000 |
| Price | : | P.O.A. |
| Description | : | |
|
turning diameter 210mm
turning length 155mm control Fanuc 8i-T max. bar capacity 42mm spindle nose A2-5 chucking diameter 165mm Main spindle: turning speed range - main spindle 55 - 5.500min/-1 power capacity - main spindel 7,5 / 5,5kW C-Axis 0,001° Subspindel: Spindle speed range subspindle 55 - 5.500min/-1 power capacity - Sub spindle 7,5 / 5,5kW C-Axis 0,001° turret: Number of Turret 2pos number of toolpositions 2 x 12pos. Number of driven toolspositions 2 x 12pos Driven Tool Positions: Number of driven toolspositions 2 x 12pos Spindle speed - driven tools 60 - 6.000min -1 power capacity - driven tools 2,2 / 1,5kW axis stroke: x-travel 1 / 2 : 180mm z-travel 1: 200 / 2: 620mm feeds: rapid traverse X: 16 / Z: 40m/min total power requirement 77kVA weight of the machine ca. 5,2t dimensions of the machine ca. 5,0 x 2,5 x 2,0m Equipment Chip conveyor Subspindle Turret 2x bar feeder interface hydraulic system driven tool positions Other information CNC - Turning- and MillingCenter NAKAMURA - TW 10 MM - Main- and Subspindle - 2 turrets - driven toolpositions | ||
| View all |
|
NAKAMURA (13) TW 10 MM (1) CNC Lathes (382) Turning Centres (337) |
Germany
