| Stockcode | : | 667093 |
| Type | : | CNC Lathes |
| Subtype | : | Turning Centres |
| Manufacturer | : | DOOSAN |
| Model | : | PUMA 2000SY |
| Year | : | 2006 |
| Price | : | P.O.A. |
| Description | : | |
|
Swing Over Bed: 23.6" Swing Over Carriage: 21.6" Max Cutting Dia: 13" Distance Between Spindles: 33.8" Chuck Size Main/Sub Spindle: 8"/6" X Travel: 9.84" Y Travel: 3.94" Z Travel: 22.8" Max Bar Capacity: 2.625" Max Machining Length: 20.1" Main Spindle Speed: 45-5,000 RPM Sub Spindle Speed: 60-6,000 RPM Spindle Nose/Bore: A2-6" / 2.99" Spindle Motor Main/Sub: 20 HP /10 HP Spindle Indexing: .001 Degree Turret Positions: 12 Rapid Traverse Rates X / Z: 740 / 945 IPM Utilization: Brass and Aluminum Hours: 7,800 Cycle hours Equipped with: Fanuc 18iTB CNC Control Full 'C' axis on both Spindles 6" Sub-Spindle Chuck Collet Chuck on Main Spindle Chuck Automatic Tool Presetter Rigid Tapping On Both Spindles/ Live Tooling Tool Monitoring System Box Way Construction Turbo Systems Chip Conveyor SMW Space Saver 2200 Barfeed Sold Seperately ($7,950.00) "Y" Axis Traverse Running on 208 Volt 3-Phase Many Eppinger Live Tools Available for ($900.00) Approximate Dimensions: 123"(LR) X 67"(FB) X 88"(H) Approximate Weight: 11,000 Lbs. | ||
