| Stockcode | : | 660646 |
| Type | : | CNC Machining Centres |
| Subtype | : | Vertical |
| Manufacturer | : | HAAS |
| Model | : | VF-5/50 |
| Year | : | 2005 |
| Price | : | P.O.A. |
| Description | : | |
|
HAAS, VF-5/50, 38" X, 26" Y, 25" Z,
NEW: 2005 SPECIFICATIONS: TRAVELS X AXIS: 38 " Y AXIS: 26 " Z AXIS: 25 " A AXIS (TILT): ±120 ° B AXIS (ROT): 360 ° SPINDLE NOSE TO TABLE (~ MIN): -0.85 " SPINDLE NOSE TO TABLE (~ MAX): 24.15 " SPINDLE MAX RATING: 30 HP MAX SPEED: 7500 RPM MAX TORQUE: 450 FT-LB @ 500 RPM DRIVE SYSTEM: 2-SPEED GEARED HEAD GEARBOX STANDARD: GEARBOX STANDARD TAPER: 50 FEEDRATES RAPIDS ON X: 710 IN/MIN RAPIDS ON Y: 710 IN/MIN RAPIDS ON Z: 710 IN/MIN MAX CUTTING: 500 IN/MIN AXIS MOTORS MAX THRUST X: 5600 LB MAX THRUST Y: 5600 LB MAX THRUST Z: 5600 LB TOOL CHANGER TYPE: SMTC CAPACITY: 30+1 MAX TOOL DIAMETER (ADJACENT EMPTY): 7 " MAX TOOL DIAMETER (FULL): 4 " MAX TOOL LENGTH (FROM GAGE LINE): 16 " MAX TOOL WEIGHT: 30 LB TOOL-TO-TOOL (AVG): 4.2 SEC CHIP-TO-CHIP (AVG): 6.3 SEC ACCURACY POSITIONING (±) : 0.0002 " REPEATABILITY: 0.0001 " GENERAL AIR REQUIRED: 4 SCFM, 100 PSI COOLANT CAPACITY: 55 GAL POWER (OPTIONS MAY INCREASE REQUIREMENT): 195-260 VAC/100 A/354-488 VAC/50 A MACHINE WEIGHT: 17000 LB EQUIPPED WITH: -10,000RPM -16 MEG MEMORY -4TH AXIS PREWIRE -4TH AXIS ROTARY -HIGH SPEED MACHINING -24 SIDMOUNT ATC -EXTRA RAPID TRAVERSE -50 TAPER -80 GALLON COOLENT TANK 4100 SPINDLE HOURS | ||
