| Stockcode | : | 659237 |
| Type | : | CNC Lathes |
| Subtype | : | Turning Centres |
| Manufacturer | : | CLAUSING |
| Model | : | METOSA |
| Year | : | 1998 |
| Price | : | P.O.A. |
| Description | : | |
|
Specifications:
Swing/Max. part diameter 15.75"/8.25" Max. turning length 65" Tailstock Manual Bar capacity 2.03" bore Spindle speeds 0-2300 RPM Spindle HP 10 CNC control Fagor 800T Rapids 393 ipm * Swing over bed 15.75" * Swing over carriage 14.5" * Swing over cross slide 8.25" * Centers 65" * Travels X 12", Z 65" * Spindle nose D1-6 * Spindle bore 2.03" * Tailstock quill taper MT#5 * Tailstock quill dia. 2.3" * Tailstock stroke 6.2" * Approx. dimensions 121 x 57 x 62" · Approx. weight 5,000 lbs Equipped with: * FAGOR 800T CNC CONTROL WITH 9" CRT SCREEN * RS-232C PORT INTERFACE FOR DNC OPERATION * CONSTANT SURFACE SPEED * INCH/METRIC THREADING * 2 ELECTRONIC HANDWHEELS (X/Z) * MANUAL TAILSTOCK WITH HANDLE-FEED OUT QUILL * STANDARD COOLANT SYSTEM WITH TANK & PUMP * ALL AVAILABLE TOOL HOLDERS · ALL AVAILABLE MANAULS | ||
| View all |
|
CLAUSING (1) METOSA (1) CNC Lathes (382) Turning Centres (337) |
United States
