| Stockcode | : | 659235 |
| Type | : | CNC Lathes |
| Subtype | : | Turning Centres |
| Manufacturer | : | CITIZEN |
| Model | : | E-25J |
| Year | : | 1994 |
| Price | : | P.O.A. |
| Description | : | |
|
SPECIFICATIONS
CONTROL: MITSUBISHI 320LC NO. OF SIMULTANEOUSLY CONTROLLED AXES: 5 (X1, X2, Z1, Z3, C1) MAXIMUM MACHINING DIAMETER: 1" MAXIMUM MACHINING LENGTH: 9.84" MAXIMUM DRILLING DIAMETER: 1/2" MAXIMUM THREADING DIAMETER (TAP & DIE): 3/8" SPINDLE SPEED: 150-7000 RPM ROTARY TOOLS: MAXIMUM DRILLING DIAMETER: 5/16" SPINDLE SPEED: 300-5840 RPM BACK-WORK: MAX. CHUCKING DIAMETER OF BACK-WORK SPINDLE: 1" MAX. BACK-WORK LENGTH: 6.3" MAX. DRILLING DIAMETER: 3/8" BACK-WORK SPINDLE SPEED: 150-5000 RPM NO. OF TOOLS INSTALLABLE: 20 (10 PER TURRET) TOOL SIZE: 3/4 x 3/4 x 3.5" MAIN SPINDLE MOTOR DRIVE: 7.5 HP ROTARY TOOL SPINDLE MOTOR DRIVE: 1.0 HP BACK-WORK SPINDLE MOTOR DRIVE: 3.0 HP POWER SUPPLY: 14 KVA REQUIRED FLOOR SPACE: 59.84"x 90.16" WEIGHT (APPROX.): 8800 LB | ||
| View all |
|
CITIZEN (5) E-25J (1) CNC Lathes (382) Turning Centres (337) |
United States
