| Stockcode | : | 658334 |
| Type | : | CNC Lathes |
| Subtype | : | Turning Centres |
| Manufacturer | : | HITACHI SEIKI |
| Model | : | SUPER HICELL 250 |
| Year | : | 2001 |
| Price | : | P.O.A. |
| Description | : | |
|
Chuck Size 10" Max Diameter Bar Capacity 2.56" Max Swing Over Bed 19.68" Max Turning Dia (Live/Turning Tools) 19.68" / 14.56" Max Machining Length 28.3" Main Motor 25 / 20 HP Spindle Speed 30 - 4000 RPM Tool Positions 2 Tool Magazine 20 Spindle Bore 3.1" Spindle Nose A2-8 Sub Spindle Chuck Size 8" Sub Spindle Bar Capacity 1.65" Sub Spindle Motor 10 / 7.5 HP Rapid Traverse Rates (X&Z/Y) 1181 / 590 IPM X-Axis Travel 23.6" Z-Axis Travel 39.5" C-Axis Index (Main & Sub) .001 Degrees Y-Axis Travel +/- 2.95" B-Axis Index 5 Degrees Milling Speed 80 - 8000 RPM Milling Motor 10 / 7.5 HP Max Tool Diameter 3.9" Max Tool Length 9.8" Max Tool Weight 15 lbs. Tailstock Taper MT #5 Machine Weight 17,600 lbs. FEATURES: - SEICOS SIGMA 16T CNC CONTROL - C, Y & B-Axis Milling Capability - Programmable Sub Spindle with C-Axis - 10" & 8" Hydraulic Chucks - Q-Setter - Coolant Thru Milling Spindle - Torque Limiter Protection for X, Y, & Z Axes - Chip Conveyor
| ||
