| Stockcode | : | 658333 |
| Type | : | CNC Lathes |
| Subtype | : | Turning Centres |
| Manufacturer | : | MORI SEIKI |
| Model | : | NL-2000/500 |
| Year | : | 2007 |
| Price | : | P.O.A. |
| Description | : | |
|
SWING OVER BED .................. 36.4" INTERFERENCE WITH FRONT COVER ... 22.8" SWING OVER CROSS SLIDE .......... 29.7" MAX. TURNING DIAMETER ........... 14" BAR WORK CAPACITY ............... 2.5" X-AXIS TRAVEL ................... 10.2" Z-AXIS TRAVEL ................... 23.2" MAX. SPINDLE SPEED .............. 5,000 RPM TYPE OF SPINDLE NOSE ............ A2-6 THRU SPINDLE HOLE DIAMETER ...... 2.9" NUMBER OF TOOL STATIONS ......... 12 SHANK HEIGHT FOR SQUARE TOOL .... 1" SHANK DIAMETER FOR BORING BAR ... 2" TURRET INDEXING TIME ............ 0.2 Sec. RAPID TRAVERSE X/Z .............. 1181 IPM TAILSTOCK TRAVEL ................ 22.2" TAILSTOCK SPINDLE DIAMETER ...... 3.1" TAILSTOCK TAPER ................. MT4 SPINDLE DRIVE MOTOR ............. 20/15HP APPROXIMATE WEIGHT .............. 11,900 LBS. APPROXIMATE DIMENSIONS .......... 140" x 75" x 83.5" | ||
