| Stockcode | : | 658200 |
| Type | : | CNC Lathes |
| Subtype | : | Turning Centres |
| Manufacturer | : | HARDINGE |
| Model | : | CONQUEST GT-27SP |
| Year | : | 1999 |
| Price | : | P.O.A. |
| Description | : | |
|
SPECIFICATIONS: MAX SWING OVER WAY COVER ...................... 11.76" MAX SWING OVER TOP PLATE ...................... 2.65" X-AXIS TRAVEL ................................. 11.96" Z-AXIS TRAVEL ................................. 11.06" MAX SQUARE SHANK TOOL SIZE .................... 1/2" MAX ROUND SHANK TOOL SIZE ..................... 3/4" HOLE THRU SPINDLE ............................. 1.25" CAPACITY THRU 5C COLLET ....................... 1.06" 5C STEP CHUCK (GRIPPING CAPACITY) ............. 4" SPINDLE CONFIGURATION ......................... A2-4" SPINDLE SPEEDS ................................ 60-6000 RPM MAX DISTANCE FROM SPINDLE FACE TO TOP PLATE ... 11.259" AC DIGITAL SPINDLE DRIVE SYTEM ................ 5 HP EQUIPPED WITH: FANUC 18T CNC CONTROL HYD. COLLET CHUCK 12' HARDINGE HYDRAULIC BARFEED ALL AVAILABLE TOOLHOLDERS ALL AVAILABLE MANUALS OVERALL DIMENSIONS (MACHINE): 72" (LR) x 60" (FB) x 72" (H) APPROX WEIGHT ................................ 5,700
| ||
