| Stockcode | : | 675014 |
| Type | : | CNC Lathes |
| Subtype | : | Turning Centres |
| Manufacturer | : | NAKAMURA |
| Model | : | SUPER NTM3 |
| Year | : | 2008 |
| Price | : | P.O.A. |
| Description | : | |
|
Mfg. year 2008 / Installed 2011
max. turning diamter 190 mm max. bar working capacity 65 mm max. turning length – Upper turret 205 mm – Lower turret 640 mm Movements: – X1/X2/X3: 167,5/167,5/167,5 mm – Z1/Z2/Z3: 250/250/685 mm – Y1/Y2: 102/102 mm Main spindle drive AC 15 kW Main spindle max. speed 5.000 rpm A2-5 spindle nose Sub spindle drive AC 11 kW Sub spindle max. speed 6.000 rpm 2 x upper turrets with y-axis 2 x 12 driven tool stations (24 positions indexing) Driven tools AC 5,5 kW, max. speed 6.000 rpm 1 x lower turret with 12 driven tool stations (24 positions idexing) Driven tools AC 5,5 kW, max. Drehzahl 6.000 rpm Parts catcher G 1 x collet chuck Hainbuch Spanntop nova Kombi Axfix 65K6 1 x collet chuck Hainbuch Spanntop Kombi Axzug 65K5 Interface barfeeder Interface robot with handling 3x Brinkmann high pressure pumps AME coolant filter system Swarf conveyor CE-mark Power On: approx. 16.000 hours Cutting time: approx. 4.000 Hours Machine can be offered with a used Fanuc M10 robot and handling system or barfeeder on request. | ||
| View all |
|
NAKAMURA (13) SUPER NTM3 (1) CNC Lathes (382) Turning Centres (337) |
Germany
