| Stockcode | : | 670359 |
| Type | : | Lathes |
| Subtype | : | CNC Combination |
| Manufacturer | : | WOHLENBERG VDF |
| Model | : | E 1400 B |
| Year | : | 1963 |
| Price | : | P.O.A. |
| Description | : | |
|
turning length 8.000mm
turning diameter over bed 1.480mm control Siemens 810 T turning diameter over slide 1.200mm center height over square guideway 750mm faceplate diameter 1.400mm Main spindle: turning speed range - main spindle 0,9 - 180min/-1 no. of turning speeds 24 power capacity - main spindel 50kW spindle diameter in front bearing 300mm spindle bore 80mm max. workpiece weight 5 / 25 / 32 / 40t Tailstock: diameter of quill 250mm lip angle 90° feeds: feed speeds X: 0,16 - 355mm/min feed speeds Z: 0,315 - 710mm/min total power requirement 56kW weight of the machine ca. -t dimensions of the machine ca. 13,0 x 3,5 x 2,5m Equipment Documents Chip conveyor Coolantsystem Tailstock Other information CNC - Lathe WOHLENBERG VDF - E 1400 B - 1996 upgrade CNC-Control | ||
| View all |
|
WOHLENBERG VDF (3) E 1400 B (1) Lathes (281) CNC Combination (9) |
Germany
