| Stockcode | : | 670302 |
| Type | : | CNC Machining Centres |
| Subtype | : | Vertical |
| Manufacturer | : | DECKEL MAHO |
| Model | : | DMC 104 V LINEAR |
| Year | : | 2003 |
| Price | : | P.O.A. |
| Description | : | |
|
x-travel 1.040mm
y-travel 600mm z-travel 500mm control Siemens 840 D Main spindle: turning speed range - main spindle 1 - 12.000min/-1 power capacity - main spindel 19 / 13kW max. Torque 100 / 70Nm tool taper SK 40 work table: table surface area 1.250 x 600mm work height max. 850mm max. table load 800kg Tool-Presetter: number of toolpositions 30pos. max. tool diameter 100mm max. tool-dia with free toolbox 140mm max. tool length 300mm max. tool weight 7kg change-time chip to chip 6,7sec feeds: Feed force 7kN feed speeds 1 - 40.000mm/min rapid traverse ( X / Y / Z ) 70 / 40 / 40m/min total power requirement ca. 39kVA weight of the machine ca. -t dimensions of the machine ca. 5,5 x 4,5 x 3,2m Equipment Documents Chip conveyor Coolantsystem high pressure coolant through spindle coolant oil mist extraction paper band filter spindle oil cooler hydraulic system Automatic Tool Changer 30 pos. tool setting Other information CNC - Machining Center Vertical DECKEL MAHO - DMC 104 V linear - inkl. new spindle! - Operating-Hours: Power-On: 34.500h / Spindle: 0h (10.300h) | ||
| View all |
|
DECKEL MAHO (25) DMC 104 V LINEAR (1) CNC Machining Centres (475) Vertical (370) |
Germany
