| Stockcode | : | 670298 |
| Type | : | CNC Machining Centres |
| Subtype | : | Universal |
| Manufacturer | : | HERMLE |
| Model | : | C 800 U |
| Year | : | 1997 |
| Price | : | P.O.A. |
| Description | : | |
|
x-travel 800mm
y-travel 600mm z-travel 500mm control iTNC 430 Heidenhain Main spindle: turning speed range - main spindle max. 8.000min/-1 power capacity - main spindel 10 / 15kW Torque 130 / 87Nm tool taper SK 40 DIN 69871 spindle diameter in front bearing 70mm work table: Clampingarea 3x max. 900 x 200mm Swivel range 360° max. table load 3x 50kg max. workpiece sizes 900 x 200 x 220mm circle diameter max. 670mm Tool-Presetter: number of toolpositions 30pos. max. tool diameter 80mm max. tool-dia with free toolbox 125mm max. tool length 300mm max. tool weight 8kg change-time chip to chip 6,0sec feeds: Feed force 8kN rapid traverse 30m/min feed speeds 1 - 30.000mm/min total power requirement max. 43kVA weight of the machine ca. 7,6t dimensions of the machine ca. 5,0 x 4,0 x 3,0m Equipment Documents Chip conveyor Coolantsystem high pressure coolant through spindle coolant oil mist extraction interface 4. axis 4. axis Hermle spindle oil cooler hydraulic system Automatic Tool Changer 30 pos. elektr. hand wheel Other information CNC-Machining-Center Vertical HERMLE - C 800 U - incl. 4th Axis (Bridge & Counter Bearing) - Operating-Hours: ca. 25.000h Power-On / ca. 8.000h Spindleruntime | ||
