| Stockcode | : | 670281 |
| Type | : | CNC Machining Centres |
| Subtype | : | Horizontal |
| Manufacturer | : | BURKHARDT-WEBER |
| Model | : | MC 120 |
| Year | : | 1992 |
| Price | : | P.O.A. |
| Description | : | |
|
x-travel 2.800mm
y-travel 1.600mm z-travel 1.250mm control Siemens 850 M Main spindle: turning speed range - main spindle 20 - 4.000min/-1 power capacity - main spindel 37kW max. Torque 2.150Nm transmission ratio 4 spindle diameter in front bearing 130mm tool taper A 50 pallet changer: size of pallet 1.800 x 1.400mm B-Axis 360 x 1° max. palett load 6.000kg change time of pallets 70sec switching time 6,5 - 16sec tool magazin: number of toolpositions 140pos. max. tool diameter 125mm max. tool-dia with free toolbox 350mm max. tool length 700mm max. tool weight 40kg change-time tool to tool 9sec change-time chip to chip 15sec feeds: rapid traverse ( X / Y / Z ) 15m/min feed speeds max. 15.000mm/min Feed force 27 / 54kN total power requirement ca. 85kW weight of the machine ca. 65,0t dimensions of the machine ca. 11,0 x 15,0 x 5,0m Equipment Documents Chip conveyor hydraulic system Coolantsystem paper band filter central lubrication pallet changer Tool Magazine 140 pos. Other information CNC-MachiningCenter Horizontal BURKHARDT & WEBER - MC 120 | ||
| View all |
|
BURKHARDT-WEBER (3) MC 120 (1) CNC Machining Centres (475) Horizontal (148) |
Germany
