| Stockcode | : | 670277 |
| Type | : | CNC Machining Centres |
| Subtype | : | Horizontal |
| Manufacturer | : | DÖRRIES-SCHARMANN |
| Model | : | SOLON 3 |
| Year | : | 1992 |
| Price | : | P.O.A. |
| Description | : | |
|
x-travel 1.600mm
y-travel 1.000mm z-travel 1.000mm control Sinumerik 880M Siemens b-axis 360° type of pallet-changer 2pos. size of pallet 800 x 1.000mm workpiece weight 2.500kg Rapid B-Axis 5,56min/-1 work height max. 1.300mm turning speed range - main spindle 12 - 4.500min/-1 power capacity - main spindel 30kW spindle diameter 130mm tool taper SK 50 DIN 69871A rapid traverse 15m/min feed 1 - 15.000mm/min tool change unit 155pos. max. tool weight 20kg max. workpiece length 1.575mm max. workpice width 900mm total power requirement 40kW weight of the machine ca. 32t dimensions of the machine ca. 8,5 x 9,0 x 4,0m Equipment Documents Chip conveyor Coolantsystem through spindle coolant 18 bar oil mist extraction Signal-Light paper band filter B-axis 0,001° spindle oil cooler hydraulic system Automatic Tool Changer 155 pos. pallet changer 2 pos. Renishaw Other information MachiningCenter - Horizontal DOERRIES SCHARMANN - Solon 3 | ||
| View all |
|
DÖRRIES-SCHARMANN (2) SOLON 3 (1) CNC Machining Centres (475) Horizontal (148) |
Germany
