| Stockcode | : | 659584 |
| Type | : | Grinding |
| Subtype | : | CNC Cylindrical |
| Manufacturer | : | GER |
| Model | : | C-1500-CNC |
| Year | : | 1998 |
| Price | : | € 33,000.00 EUR |
| Description | : | |
|
1500 MM BETWEEN CENTERS
MAX. LOAD BETWEEN CENTERS: 240 KGS FREE MAX. LOAD: 60 KGS WHEEL 400 X 50/80 X 127 MM CNC FAGOR 8050 MAX. GRINDING DIAMETER 350 MM CENTERS HEIGTH 140 MM Z AXIS TABLE MAX. STROKE: 1680 MM MAX. FEED: 6 M/MIN MIN FEED: 0,1 M/MIN X AXIS MAX. STROKE: 350 MM FAST FEED: 40 MM INCREMENTAL FEED: 0,005-0,04 MM TAILSTOCK QUILL DIAMETER: 50 MM QUILL STROKE: 30 MM TAPER: 4 POWER REQUIREMENT: 8,75 kw MAIN MOTOR 7,5 HP MACHINE WEIGHT: 4500 KGS | ||
| View all |
|
GER (4) C-1500-CNC (1) Grinding (304) CNC Cylindrical (9) |
Spain
  |  |
