| Stockcode | : | 659159 |
| Type | : | Lathes |
| Subtype | : | Vertical |
| Manufacturer | : | PITTLER |
| Model | : | PV-315/2-2 |
| Year | : | 1990 |
| Price | : | P.O.A. |
| Description | : | |
|
Control Siemens 850T
Swing diameter over the bed: 500 mm Turning diameter: max. 400 mm Turning length: max. 450 mm Travels Support 1/Support 2: X1/X2 350 / 350 mm Z1/Z2 450 / 450 mm Rapids: X/Z 16000 mm/min. Spindle bearing diameter left/right: 130 mm Spindle drive motor rating left/right: 42 kW Spindle speeds left/right: 28 - 2500 rpm Spindle torque left/right: 1166 Nm Chuck diameter left/right: 315 mm Chuck type: Hydraulic 3-jaw Turret tool positions left/right: 4-station turrets Machine weight: 13000 kg Equipped with: Two independant spindles and two independant turrets; Loading system for parts upto 300 mm diameter, including workpiece turnover station; Parts conveyor; Tool monitor; Loaded with spare parts and accessories; Chip conveyor; Condition: Loader defect, but easily reparable. X Axis slides with slight scoring, machine producing parts of 0.07 tolerances without problems. Mechanically and optically sound; Ideal for high series of cirlular parts needing average accuracies and low cost ! | ||
| View all |
|
PITTLER (3) PV-315/2-2 (1) Lathes (281) Vertical (370) |
Germany
    |  |
