| Stockcode | : | 658300 |
| Type | : | CNC Machining Centres |
| Subtype | : | Vertical |
| Manufacturer | : | MONARCH |
| Model | : | VMC-150A |
| Year | : | 1991 |
| Price | : | P.O.A. |
| Description | : | |
|
MACHINE SPECIFICATIONS: TABLE WORKING SURFACE.................... 30" x 60" OVERALL TABLE SIZE....................... 34-1/2"x64-1/2" TABLE TRAVEL, X-AXIS (LONGITUDINAL)...... 50" TABLE TRAVEL, Y-AXIS (CROSS)............. 36" SPINDLE SLIDE TRAVEL, Z-AXIS............. 10" VERTICAL SLIDING HEAD ADJUSTMETN, W-AXIS. 23" MIN./MAX. HEIGHT, SPINDLE NOSE TO TABLE.. 0" / 34" DIST. CENTERLINE TO COLUMN............... 33-1/2" TABLE LOAD CAPACITY...................... 3,000 LBS. QUILL DIAMETER........................... 5-3/4" QUILL TRAVERSE RATE...................... 400 IPM QUILL FEED RATE.......................... 0.01 TO 400 IPM SPINDLE TAPER............................ #45 ASA SPINDLE SPEEDS........................... 30 TO 5,200 RPM TABLE & SADDLE POSITION SPEED............ 400 I.P.M. POWER ELEVATION OF HEAD, TRAVERSE RATE... 100 I.P.M. EQUIPPED WITH: FANUC 15MA CNC CONTROL HYPERINDEX 360 DEGREE INDEXER | ||
