| Stockcode | : | 654013 |
| Type | : | Lathes |
| Subtype | : | CNC Multispindle |
| Manufacturer | : | LEAD |
| Model | : | LTC 20 AP |
| Year | : | - |
| Price | : | £ 12,950.00 GBP |
| Description | : | |
|
Swarf Conveyor: Yes
Collet Chuck: Yes Bar feed: Hydropack Bar Feeder. Control: Fanuc OT Turning Diameter (mm): 125mm Turning Length (mm): 600mm Tool setter arm: yes Bar Capacity: 50mm Number Of Controlled Axis: 2 Maximum Swing: 200mm Main Drive Power (KW/V/Hz): 415volts/3 phase/50 Tailstock: yes Spindle Bore (mm): 50mm Chucking Diameter (mm): 125mm Powered Tailstock: yes Number Of Tools Per Turret: 12 Travel Of Turret Slide: 600mm Spindle Turning Speed Range: 60-4000rpm Parts Catcher: Yes Z Stroke: 620mm X Dimension: 288 Hydraulic Tail Stock: yes Turret: 12 station Chuck Diameter: 200mm | ||
