| Stockcode | : | 651143 |
| Type | : | Presses |
| Subtype | : | Miscellaneous |
| Manufacturer | : | BLOW |
| Model | : | GD105 |
| Year | : | - |
| Price | : | P.O.A. |
| Description | : | |
|
CAPACITY 105 TON
STROKE 6" STROKE SHUT HEIGHT OVER BED 16" S.D.A.U. SLIDE ADJUSTMENT 5" (POWER) BED AREA ( F -B X L-R ) 24" x 64" RAM AREA ( F-B X L-R ) 18" X 48" SPEED APPROX. 60 S.P.M. THROAT DEPTH 10 1/4" FEATURE ARRANGED FOR (3) F-B KNOCKOUTS CLUTCH AIR CLUTCH EQUIPPED WITH PRESS-MASTER PROGRAMMABLE CONTROL SYSTEM . (2) AIR COUNTERBALANCE CYLINDERS TO SLIDE . BOLSTER PLATE (4" THICK); SUB-BOLSTER PLATE (2") . AUTOMATIC RECIRCULATING LUBRICATION SYSTEM . AC MAIN DRIVE MOTOR; ADJUSTMENT MOTOR . DUAL PALM BUTTON OPERATION(PEDESTAL MOUNTED) ELECTRICS ELECTRICAL CONTROLS WEIGHT 23,000 LBS. DIMENSIONS 100" L-R x 88" F-B x 140" H YEAR 1980 APPROX. CONDITION USED FOB POINT CHICAGO, ILL, USA | ||
