| Stockcode | : | 676386 |
| Type | : | Slotting |
| Subtype | : | Slotting |
| Manufacturer | : | BUTLER |
| Model | : | 8 INCH PRECISION TOOLROOM |
| Year | : | - |
| Price | : | £ 4,500.00 GBP |
| Description | : | |
|
BUTLER PRECISION TOOLROOM SLOTTING MACHINE
Serial number 25686 Ram stroke 1” to 8” Cutting speeds Low range 20, 27, 38, 53 s.p.m. High range 40, 54, 75 & 105 s.p.m. Work table size 20” Throat depth 19 ¾” Tool box to table at max. stroke Min. 0 Max. 16” Tool slide adjustment 10” Tilt of ram 0 – 5 degrees Work table traverse Cross 20” Front to back 20” Cross traverse feeds (7) 0.004” – 0.028” Front to back feeds (7) 0.003” – 0.021” Main drive motor 3 HP Overall size 56” Wide x 80” Front to Back x 78” High. Weight approx. 2.5 tons Complete with :- 2 speed motor, Powered cross traverse, front to back traverse and table rotation. Dividing Head to Table rotation, Toolbar holder. | ||
