Mfg. year 11/1995
Fanuc Series 21-M control
Table size: 500 mm x 305 mm
movements:
X-axis: 500 mm
Y-axis: 300 mm
Z-axis: 300 mm
distance spindle nose to table surface 150-450 mm
spindle motor AC 3,7/5,5 kW
Max. spindle speed 10.000 rpm
12-station turret, BT-30 taper
– Max. tool weight 3 kg
– Max. tool length 200 mm
Coolant pump
Coolant tank
div. BT-30 toolholders
dimensions 1.250 mm x 2.100 mm x 2.150 mm
weight 1.800 kg
electrical supply 9 kVA
CE-mark
